BDZ52-10/3防爆断路器防爆空气开关箱依客思
适用范围
1. 爆炸性气体环境危险场所：1区、2区；
2. 可燃性气体、蒸气级别：ⅡA、ⅡB；
3. 温度组别：T1~T6；
4. 户内、户外 (IP54)。
1. For the dangerous sites with explosive air mixture:
1 division、2 division;
2. Flammable gas, steam class：ⅡA、ⅡB;
3. Temperatures classification：T1~T6;
4. Indoor and outdoor(IP54).

性能特点
1. 铸铝合金外壳，压铸成形，表面喷塑；
2. 内装C45N、C45AD、或NC100H高分断小型断路器；
3. 具有过载、短路等保护功能；
4. 钢管或电缆布线。
1. Diecasted Al-alloy shell with plastic-sprayed surface;
2. Inner mounted C45nc、45AD or NC100H mini breaker with high-
breaking;
3. Possessing the guarding function against overload and short, etc;
4. Steelpipe and cable wiring.

技术参数
额定电压
Rated
voltage (V)
额定电流
Rated
current (A)
防爆标志
Explosion-
proofing marker
防护等级
Protection
category
防腐等级
Corrosion-
proofing grade
进线口螺纹
Inlet's
thread
电缆外径(mm)
Cable's outside
diameter

380
1, 3, 5, 10, 15,
20, 25, 32, 40,
50, 63, 80, 100
ExdbebⅡBT6
IP65
W, WF1, WF2
G3/4
Φ10~Φ15
G1
Φ12~Φ18
G11/4
Φ15~Φ22

BDZ52L-32 1,3,5,10,15,20,25,32A漏电防爆断路器
BDZ52L-60 40,50,60A漏电防爆断路器
BDZ52L-100 80,100A漏电防爆断路器
BDZ52L-225 150,200,225A漏电防爆断路器
BDZ52L-400  250,315,350,400A漏电防爆断路器
BDZ52L-630  500,630A漏电防爆断路器
